| Optical cover / lens type |
Polycarbonate |
|
|
| Command interface |
IR remote control |
Charger efficiency |
>90% |
| Guarantee |
5 years |
Charge controller power |
60 W |
| Materials |
Die-casting Aluminium |
|
|
| Dimmable |
Yes |
Management and gradation |
|
| Automatic Dusk to dawn detection |
Yes |
with gradation |
Yes |
|
|
Configuration possibilities |
Configurable |
| Electrical Specifications |
| Battery type |
Lithium iron phosphate battery |
Materials and finishes |
|
| Battery capacity (ampere-hour) |
>422Wh |
Total length |
780 mm |
| Battery voltage |
12.8 V |
Total width |
670 mm |
| Battery charge and discharge cycles |
2000-3000 |
Total height |
510 mm |
| Panel type |
Monocrystalline |
Color |
Gray |
| Panel voltage |
18V |
|
|
| Peak panel intensity |
80 W |
Standards and recommendations |
|
| Type of charge controller |
MPPT |
Protection index code |
IP66 |
| Network connection type |
Off grid |
Mechanical shock protection code |
IK09 |
| Battery location |
Inside Luminaire |
Terms of use |
| Initial Performance (IEC Compliant) |
|
Ambient temperature range |
-20 to +50 *C |
| Initial luminous flux |
>7800 Im |
Ambient temperature range – load |
0 to+45 °C |
| Initial proximal color temperature |
2700-6500 K |
Ambient temperature range – discharge (when the light is on) |
-20 to +50 *C |
| Color rendering index (initial) |
>70 |
Autonomy |
> 48 h (with fully charged battery) |
| Optional functions |
Profil de gradation solaire |
First 2 Hrs – On motion : 100%, without motion:30% |
| CCTV |
Yes |
|
Next 3Hrs-On motion:60%,without motion:20% |
| Extra decorative led strip light |
Yes |
|
Next 6 Hrs-On motion:30%,without motion:10% |
| Electrc supply |
Yes |
|
Rest of 1 Hrs-On motion:50%,without motion:30% |
| Adjustable module |
Yes |
|
|
